Author Internal Exp Viewer *Final version all patches,Tutorial Done* uploaded 3/3/02
NinjaFish
Lunatic

Joined: Feb 14, 2002
Posts: 13
Posted: 2002-02-26 06:30
uhm...no patcher in the "last" version? and here i thought i was gonna be able to play in full-screen mode...oh well... the app runs just fine as an app...it only crashes when i try to patch ragnarok.exe. but i guess that doesn't matter anymore

and a special note: there is likely less wrong with winxp than any other version of windows, and 90% of the people that bash the xbox speak from ignorance.


  View Profile of NinjaFish      Edit/Delete This Post   Reply with quote
Sasami
Orc Hero L.2

Joined: Feb 08, 2002
Posts: 388
From: Jurai (Currently Okayama, Japan)
Posted: 2002-02-26 07:05
How many places to I have to put around the program that it's ragexe.exe, not ragnarok.exe!
And I am not ignorant about the xbox or winxp, I have much experience with both.

[ This Message was edited by: Sasami on 2002-02-26 07:05 ]


  View Profile of Sasami   Goto the website of Sasami      Edit/Delete This Post   Reply with quote
Sasami
Orc Hero L.2

Joined: Feb 08, 2002
Posts: 388
From: Jurai (Currently Okayama, Japan)
Posted: 2002-02-26 07:06
I've decided to post the first part of my tutorial, I got bored, I'll finish the rest of it later.

Ingredients:
A programming language (c++ or VB)
an asm dissasembler (I use OLLYDBG)
patience
dr. pepper

Ok, I kept promising people that I'd do this for a while, and I finally got around to it, So here goes.

A few quick defenitions.
Hwnd - The "Handle" of a window that you use to control aspects of it.
Hdc - the "Handle to a Device Context" or a value you can use to put graphics into a window.
You can find the hdc using the api getdc(hwnd).
Api - Application Programming Interface... basically functions windows has you can call.
You can find them all in the "api viewer" in visual basic.

The first thing I did on my long quest was learn how to find the memory locations. I found a
program called winhex on http://www.download.com/ and looked in ragnaroks ram and searched for the
proper values, then had them changed, and searched for the new values, and through this I found
the new locations, pretty simple. Next, I wrote the first external exe viewer that was written
for the english server after patch 41 i think it was? I used visual basic and the following APIs.
(I tried this all out in C too and it worked fine, but I code much much faster in VB.)

=================================================================================================
FindWindow - Finds a windows hwnd with only the name
GetWindowThreadProcessId - Finds the threadprocess knowing the hwnd
OpenProcess - opens the process using the threadprocess
CloseHandle - closes the process
ReadProcessMemory - reads a memoryvalue inside the opened process
=================================================================================================

Here is an example of how to find a value.
-------------------------------------------------------------------------------------------------
thehwnd = FindWindow(vbNullString, "Ragnarok")
GetWindowThreadProcessId thehwnd, ProcessId
ProcessHandle = OpenProcess(&H1F0FFF, False, ProcessId)
ReadProcessMemory ProcessHandle, &h55ff0c, NewString, 3, 0&
-------------------------------------------------------------------------------------------------

***newhwnd,processid,and processhandle are all "longs" or 4 bytes
***NewString is of course a string... thats where the data at location &h55ff0c (or in C
0x55ff0c) will be stored, and 3 bytes will be stored according to the number after it.
***When declaring the string, declare it as:
dim stringname as string * number (you need the * number part to make it a certain length, and
not variable.)

once you have the new value in a string, you can copy it into a long or integer (4 bytes/2bytes)
with the following api.

=================================================================================================
CopyMemory - copies memory from one variable to another.
=================================================================================================

-------------------------------------------------------------------------------------------------
CopyMemory IntegerVariable, NewString, 3
-------------------------------------------------------------------------------------------------

From there, it was a simple matter of blitting it into the external window.

=================================================================================================
Textout - Outputs a text into any hdc
=================================================================================================

-------------------------------------------------------------------------------------------------
Textout me.hdc, x , y, "NewStringName", 13 <-- the last number is the length of the string.
-------------------------------------------------------------------------------------------------

so basically, i used

-------------------------------------------------------------------------------------------------
textout me.hdc, 0, 0, trim$(baseexpval) + "" + trim$(baseexpnextval) + "" +
left$(trim$(baseexpval / baseexpnextval * 100), 4) + "%"
-------------------------------------------------------------------------------------------------

Now, this is the basic thing that most of the exp programs do, but I tried to go farther and
I succeeded in some places and failed in others.

My brilliant idea was instead of textouting into my windows hdc, i wanted to textout into ROs
hdc, and it worked... somewhat... here is what it looks like.

-------------------------------------------------------------------------------------------------
thehwnd = FindWindow(vbNullString, "Ragnarok")
textout thehwnd, 0, 0, trim$(baseexpval) + "" + trim$(baseexpnextval) + "" +
left$(trim$(baseexpval / baseexpnextval * 100), 4) + "%"
-------------------------------------------------------------------------------------------------

Now, there were two problems with this code.
#1 it always put it at location 0,0
#2 it showed in the window, but always blinked

The way i solved the first one was just finding the address in memory for the x and y locations
Basically, i put the basic info window at a random location, took a screen shot, found the
x and y position in paint, searched for the value in winhex, did the same again, and found
where the x and y were stored, and changed my textout accordingly. Now, the second problem I
never did find out how to fix. To explain why it didn't work I have to explain a little about
DirectX first. DirectX usually has at least to HDCs, one that the user actually sees, the
second is a back one where all the changes occur, and on refreshes is copied onto the top one
that users see, so the user never sees any changes occuring. Basically, my program blit
onto the top one and when a refresh happened it dissapeared, and then put it back up, causing
a blinking effect. There were 3 ways I could think of fixing this
#1 Making my program blit between ragnaroks pageswap (When the bottom hdc goes to the top hdc)
and the refresh
#2 controlling the refresh myself through my program and only initiating after my thing gets blit
#3 finding the hdc of the back hdc

So... #2 was impractical, and I never did find out about #1 and #3, I just gave up after scouring
hundreds of sites, asking college professors and people who should know, and asking on message
boards. So, what was I to do to make it internal? hm...

This is about the time Arsenic posted his ArseKit link on the pak0 forums... right after
Ro-world died might I add. I liked his patching the exe approach, and this is where the assembly
came in. Before I get into the assembly I will explain the rest of the functions of the external
viewer.

Windowed Full Screen

-------------------------------------------------------------------------------------------------
Dim resizerag As WINDOWPLACEMENT
thehwnd = FindWindow(vbNullString, "Ragnarok") //gets the hwnd
GetWindowPlacement thehwnd, resizerag //gets the current window placement
SetWindowLong thehwnd, -16, GetWindowLong(thehwnd, -16) And Not 12582912 //Used for making the window not on top
SetWindowPos thehwnd, 0, 0, 0, 0, 0, 39 //same as above
resizerag.rcNormalPosition.Top = 0
resizerag.rcNormalPosition.Bottom = GetSystemMetrics(1) //screen y res
resizerag.rcNormalPosition.Left = 0
resizerag.rcNormalPosition.Right = GetSystemMetrics(0) //screen x res
SetWindowPlacement thehwnd, resizerag //Resize the window
-------------------------------------------------------------------------------------------------

Always On Top
SetWindowPos Me.hwnd, IsOnTop, 0, 0, 0, 0, 83
-1 for on top
-2 for not on top

Now on to the assembly. (I'll write it tomorrow ^_^)

[edit] I have not yet read over this and checked for grammer, spelling, or general mistakes. When I finish it I will do so.

[ This Message was edited by: Sasami on 2002-02-26 07:44 ]


  View Profile of Sasami   Goto the website of Sasami      Edit/Delete This Post   Reply with quote
PikaPuff
Orc Hero

Joined: Feb 09, 2002
Posts: 332
From: Hawaii
Posted: 2002-02-26 07:15
*faints from big post* if i ever finish my ics111 homework, i'll try to read that...

anyways, i want a sp/hp viewer because:

when i sit or stand still to regain hp (thief) or sp (mage) i alt+tab out to read these forums (or whatever)

so i can't see my hp/sp total on RO. and since your program (ext version) is tiny, and has the 'always on top' function...

so i can read the forums and just glance at the sp/hp counter to know when i'm at full hp/sp and go back into the game.

hehe and if you want to go nuts (which i don't) you can find the value for the quantity of the first item in your vending box, so you can sell pots in the first slot, and clance at the counter to know when to go in the shop and refill
_________________

PikaPuff, Jesse Dioquino, The Puff
Look At My Balls!


  View Profile of PikaPuff   ICQ status             Edit/Delete This Post   Reply with quote
monkeyfishhead
Spore

Joined: Feb 08, 2002
Posts: 136
From: USA California
Posted: 2002-02-26 07:19
so....your final version of the expviewer doesnt work with xp? the one you released before that worked with my xp home edition...but i guess your done with it...so ill just stick with the one before that..if thatll even work...

[edit]: ok it works with my xp h.e. thanks for your cool prog sasami!!!

_________________
JOOBNESSSSSS!

meow...im a cat

[ This Message was edited by: monkeyfishhead on 2002-02-26 07:30 ]


  View Profile of monkeyfishhead      Edit/Delete This Post   Reply with quote
Lord Gien
Fabre

Joined: Feb 09, 2002
Posts: 28
Posted: 2002-02-26 07:23
Quote:

On 2002-02-26 02:40, Sasami wrote:
Ah, so NinjaFish is just crazy
or does it crash w/o my patch too? I hear some peoples RO games constantly crash.



Mines crashed without your patch, but rarely.


  View Profile of Lord Gien      Edit/Delete This Post   Reply with quote
Sasami
Orc Hero L.2

Joined: Feb 08, 2002
Posts: 388
From: Jurai (Currently Okayama, Japan)
Posted: 2002-02-26 07:28
Quote:

On 2002-02-26 07:19, monkeyfishhead wrote:
so....your final version of the expviewer doesnt work with xp? the one you released before that worked with my xp home edition...but i guess your done with it...so ill just stick with the one before that..if thatll even work...




when I finish my tuturoial, you should be able to figure it out yourself ^_^ if not, I will get around to finding them.


And mine rarely crashes also, some peoples crash constantly. His problem though was because he was patching the wrong exe.


  View Profile of Sasami   Goto the website of Sasami      Edit/Delete This Post   Reply with quote
DarkByte
Fabre

Joined: Feb 08, 2002
Posts: 30
From: Montreal, Qc, Canada
Posted: 2002-02-26 07:34
HDC: Handle to a Device Context
API: Application Programming Interface

Good job on the viewer btw.
Reason i mentioned the "tip" is because it pops every time i start the proggie. Not that i start it that often, but sometimes i switch between collapsed and full size and this pops. No biggie actually.


  View Profile of DarkByte   ICQ status       Edit/Delete This Post   Reply with quote
Sasami
Orc Hero L.2

Joined: Feb 08, 2002
Posts: 388
From: Jurai (Currently Okayama, Japan)
Posted: 2002-02-26 07:42
ah, so thats what they stand for ^_^ I had forgotten both of those a long time ago hehe

oops, my mistake, i'll go fix that.

[edit] new fixed version uploaded, also changed the title bar so it no longer says patch 51 hehehe

[ This Message was edited by: Sasami on 2002-02-26 07:50 ]


  View Profile of Sasami   Goto the website of Sasami      Edit/Delete This Post   Reply with quote
DarkByte
Fabre

Joined: Feb 08, 2002
Posts: 30
From: Montreal, Qc, Canada
Posted: 2002-02-26 07:49
Humm .. i've been working on my personal version of the viewer (external only) and i'm not getting the lastkill base/job exp. Am i forgetting something ?

  View Profile of DarkByte   ICQ status       Edit/Delete This Post   Reply with quote
Sasami
Orc Hero L.2

Joined: Feb 08, 2002
Posts: 388
From: Jurai (Currently Okayama, Japan)
Posted: 2002-02-26 07:53
I forgot to put that into the tutorial. I'll add that tomorrow. Just make an extra variable that stores the kill, and when it changes, subtract them, theres your last kill exp, store that in a variable, then in your first variable, put the new exp.

a=currentexp
while(1!=2) //loop forever
{
. if a!=currentexp
. {
. . b=currentexp-a //last kill
. . a=currentexp
. }
}

[edit to add .s to see nested programming.]

[ This Message was edited by: Sasami on 2002-02-26 07:56 ]


  View Profile of Sasami   Goto the website of Sasami      Edit/Delete This Post   Reply with quote
DarkByte
Fabre

Joined: Feb 08, 2002
Posts: 30
From: Montreal, Qc, Canada
Posted: 2002-02-26 07:58
DOH !!!!!!!!!

I feel stupid now I guess i just was expecting to find the values in ram.


  View Profile of DarkByte   ICQ status       Edit/Delete This Post   Reply with quote
PikaPuff
Orc Hero

Joined: Feb 09, 2002
Posts: 332
From: Hawaii
Posted: 2002-02-26 08:24
hm... been around 3 years since i've worked with c++

... i'll just read your tutorial and make my own version with hp/sp...

i''ll probably still end up asking you how to find values
_________________

PikaPuff, Jesse Dioquino, The Puff
Look At My Balls!


  View Profile of PikaPuff   ICQ status             Edit/Delete This Post   Reply with quote
Snorks
Willow

Joined: Feb 09, 2002
Posts: 56
Posted: 2002-02-26 08:36
Just a couple of questions. How did you determine what the proper values were? Also, how did you find them in the new locations? I hope I don't sound too dumb.

  View Profile of Snorks      Edit/Delete This Post   Reply with quote
S#arp
Pupa

Joined: Feb 26, 2002
Posts: 1
Posted: 2002-02-26 09:08
Hey Sasami, I am very interested in the Auto Dealer script you are about to write. I think it's very cool. I dunno how you can make a script that "integrates" into the game, not an external program. Item_Collector got his own script and it works great. So if you release your script, it will cost 1 million zenies? Whoa I dunno when I can afford that Keep up the good work, it would still be cool to see your source code, knowing how it is done ^^

  View Profile of S#arp      Edit/Delete This Post   Reply with quote
